Boundary Dimensions
d 12 mm Bore diameter
D 37 mm Outside diameter

B 17 mm Width

r (min.) 1 mm Chamfer dimension
Basic Load Ratings
Cr 13300 N Basic dynamic load rating
C0r 2730 N Basic static load rating
Speeds
Grease 17000 min-1 Grease lubrication
Oil (Oil-bath) 22000 min-1 Oil-bath lubrication
Abutment and Fillet Dimensions
da (min.) 17 mm Diameter of shaft abutment
Da (max.) 32 mm Diameter of housing abutment
ra (max.) 1 mm Radius of shaft or housing fillet
Calculation factors
e 0.6 Constant
Y2 1.6 Axial load Factors
Y3 1.1 Axial load Factors
Y0 1.1 Axial load Factors
Mass

(approx.) 0.082 kg

<>NSK 2301 bearing
