Bearing Type Ball Bearing
Body Outside Diameter 250.00 millimeters
Bore Diameter 140 millimeters
Compatible Lubricant Type Oil
Dynamic Load Capacity 160000 pounds

Flange Thickness 68.00 millimeters

Inside Diameter 140 millimeters
Item Diameter 250 millimeters
Item Thickness 68.00 millimeters
Item Weight 30.1 pounds
Maximum Rotational Speed 3200 rpm
Measurement System millimeters
Model Number 22228 CCK/C3W33
Number of Items 1
Outside Diameter 250 millimeters
Part Number 22228 CCK/C3W33
Specification Met DIN 623-1 , ISO 281 , ISO 492 , ISO 683-17 , DIN ISO 281
Static Load Capacity 202000 pounds
Width 68 millimeters


, Tapered Bore, Lubrication Groove, 3 Hole Outer Ring, Unsealed, Steel Cage, C3 Clearance, Metric, 140mm Bore, 250mm OD, 68mm Width, 3200rpm Maximum Rotational Speed, 202000lbf Static Load Capacity, 160000lbf Dynamic Load Capacity

<>$499 SKF 22228 CCK/C3W33 Explorer Spherical Roller Bearing
