FAG 6203ZR Deep Groove Ball Bearing, Single Row, ABEC 1 Precision, Single Shield, Steel Cage, Normal Clearance, Metric, 17mm ID, 40mm OD, 12mm Width, 18000rpm Maximum Rotational Speed, 1060lbf Static Load Capacity, 2160lbf Dynamic Load Capacity
Specifications for this item
Bearing Type
Ball Bearing
Bore Diameter
17 millimeters
Brand Name
FAG Bearings
Compatible Lubricant Type
Grease
Dynamic Load Capacity
2160 pounds
Item Diameter
40 millimeters
Material
Alloy Steel
Maximum Rotational Speed
18000 rpm
Measurement System
Metric
Number of Items
1
Part Number
6203-Z
Specification Met
Din 623-1 , Iso 281 , Iso 683-17 , Iso 199 , Din Iso 281 , En 10139 , Sae J403
Static Load Capacity
1060 pounds
UNSPSC Code
31171500
Width
12 millimeters
